Stainless Steel Wire Mesh

304 Stainless Steel Wire Mesh


304 stainless steel wire mesh is a type of wire mesh made from 304-grade stainless steel, which is an alloy containing chromium and nickel. This particular grade of stainless steel is known for its excellent corrosion resistance, making it suitable for various applications in environments where rust and corrosion are a concern

Description

304 Stainless Steel Wire Mesh

304 stainless steel wire mesh is a type of wire mesh made from 304-grade stainless steel, which is an alloy containing chromium and nickel. This particular grade of stainless steel is known for its excellent corrosion resistance, making it suitable for various applications in environments where rust and corrosion are a concern.

Key Features And Uses

Corrosion Resistance: 304 stainless steel wire mesh is highly resistant to corrosion and oxidation, making it ideal for use in marine environments, outdoor applications, and areas with exposure to moisture and harsh chemicals.

Strength and Durability: The inherent strength of stainless steel ensures that 304 wire mesh is durable and capable of withstanding heavy loads and mechanical stresses.

Hygienic Properties: The smooth and non-porous surface of stainless steel makes it easy to clean and maintain, making 304 wire mesh suitable for applications in the food and pharmaceutical industries where hygiene is critical.

Temperature Resistance: 304 stainless steel wire mesh can withstand a wide range of temperatures, making it suitable for both high-temperature and cryogenic applications.

Versatility: 304 stainless steel wire mesh comes in various mesh sizes and wire diameters, making it versatile for a wide range of applications, including filtration, screening, fencing, and reinforcement.

Ventilation and Airflow: The open structure of wire mesh allows for good ventilation and airflow, making it suitable for applications where air circulation is important, such as HVAC systems and air vents.

Insect Protection: 304 stainless steel wire mesh serves as an effective barrier against insects and pests while allowing natural light to enter the space.

Decorative Applications: Due to its clean and attractive appearance, 304 wire mesh is also used for decorative purposes in architectural projects, interior design, and artistic installations.

Chemical Resistance: 304 stainless steel exhibits good resistance to a wide range of chemicals, making it suitable for applications in chemical processing and industrial environments.

Petroleum and Oil Industry: This type of wire mesh is commonly used in the petroleum and oil industry for filtering and separating processes.

Mining and Quarrying: 304 stainless steel wire mesh finds applications in mining and quarrying industries for screening and sorting minerals and aggregates.

Security Fencing: Its strength and durability make 304 wire mesh an excellent choice for security fencing, protecting commercial and residential properties.

Water Filtration: The fine mesh size and corrosion resistance make it suitable for water filtration and purification systems.

Industrial and Laboratory Sieving: 304 stainless steel wire mesh is used in industrial sieving and particle size analysis, as well as in laboratory settings.

Beverage and Brewing Industry: The corrosion-resistant properties of 304 stainless steel make it suitable for use in the beverage and brewing industry for filtering and processing liquids.304 stainless steel wire mesh / 316 stainless steel wire cloth / 430 stainless steel wire mesh / duplex2205/2207stainless steel wire mesh

parameter

Specification

Material: AISI302, 304, 316, 316L, 310S, 410, 430, 904L, 2205, 2507, etc

Wire Diameter: 0.015-2.8mm

Mesh count:

Plain weave can be woven up to 400 mesh.

Twill weave can be woven from 400 to 635mesh.

Dutch weave can be woven up to 3500mesh

4.Weave pattern: Plain Weave, Twill Weave, Dutch Weave, etc.

Stainless Steel Wire Mesh
Mesh/inchWire Diameter
(mm)
Aperture
(mm)
Mesh/inchWire diameter
(mm)
Aperture
(mm)
2mesh1.8010.9060mesh0.150.273
3mesh1.606.86670mesh0.140.223
4mesh1.205.1580mesh0.120.198
5mesh0.914.1790mesh0.110.172
6mesh0.803.433100mesh0.100.154
8mesh0.602.575120mesh0.080.132
10mesh0.551.990140mesh0.070.111
12mesh0.501.616150mesh0.0650.104
14mesh0.451.362160mesh0.0650.094
16mesh0.401.188180mesh0.0530.088
18mesh0.351.060200mesh0.0530.074
20mesh0.300.970250mesh0.040.061
26mesh0.280.696300mesh0.0350.049
30mesh0.250.596325mesh0.030.048
40mesh0.210.425350mesh0.030.042
50mesh0.190.318400mesh0.0250.0385
Width of Stainless Steel Wire Mesh: 0.6m-8m


The main materials are 304 stainless steel wire mesh, 316 stainless steel wire mesh, 310 stainless steel wire mesh, 904L stainless steel wire mesh, 430 stainless steel wire mesh, and other stainless steel grade. The most popular ones are 304 stainless steel wire mesh and 316 stainless steel wire mesh, which can be used in most application environments and are not expensive. And some special materials are used to meet the high requirements of the use environment, such as Inconel wire mesh, Monel Wire Mesh, Titanium Wire Mesh, Pure Nickel Mesh, and Pure Silver Mesh, etc.

We can customized stainless steel wire mesh products
by your drawing and requirements
